3-3
3. Disassembly and Reassemble
Description Picture Description Screws
10. Remove 4 screws.
11. Remove 5 screws and Lift up the Bracket
Support.
Bracket Support
12. Lift up the Main PCB and IB Board.
13. Main PCB and IB Board.
Reassembly procedures are in the reverse order of disassembly procedures.※
To Next Page
