6. HDMI2 - This is deactivated when a network box is installed.
7. DisplayPort
8. MagicInfo - A network box must be connected to use MagicInfo with a MX-3, MP-3 model.
9. TV- Enabled if a TV tuner box is connected.
Note
The [RGB/COMPONENT IN] port is compatible with RGB (PC) and Component signals.
However, the picture may display abnormally if the connected external input signal is different from
the selected video signal.
PIP
Note
The PIP function is not available when Video Wall is On.
When external AV devices such as VCRs or DVDs are connected to the LCD Display , PIP allows
you to watch video from those devices in a small window super-imposed on the PC Video signal.
(Off/On)
Note
• PIP turns off when the LCD Display is switched to an external source.
•
If you select , , in Size, Position and Transparency will not be activated.
PIP
Turns the PIP Screen Off/On.
• Off
• On
Source
Selects the input source for the PIP.
Adjusting the LCD Display
