5 Disassembly and Reassembly
SyncMaster 320TFT/520TFT 5-5
5-3 Replacement Order of Lamp Assemblies (15”)
1. Disconnect lamp lead-
connectors from the inverter.
(2EA)
* Replacement of lamp assemblies
should be done at the power off
state and recommended clean
bench condition.
2. Remove 2 screws which are
used to hold the lamp
assemblies on.
3. Replace 2 lamp assemblies.
4. Assemble new lamp
assemblies according to the
counter order.
To Next Page
