5 Disassembly and Reassembly
5-4 SyncMaster 320TFT/520TFT
5-2 Replacement Order of Lamp Assemblies (13.3”)
1. Disconnect lamp lead-
connector from the inverter.
* Replacement of lamp assemblies
should be done at the power off
state and recommended clean
bench condition.
2. Remove a screw which is
used to hold a lamp
assembly on.
3. Replace lamp assemblies.
4. Assemble new lamp
assembly according to the
counter order.
