Samsung SyncMaster 320TFT - Page 37

BD801 3301-000011 CORE-FERRITE BEAD AA,3.5x1.0x5.7mm,1500,2375G
BD802 3301-000011 CORE-FERRITE BEAD AA,3.5x1.0x5.7mm,1500,2375G
BD803 3301-000011 CORE-FERRITE BEAD AA,3.5x1.0x5.7mm,1500,2375G
C801 2401-000164 C-AL 1000uF,20%,25V,WT,12.5x20mm,5m
C802 2201-000177 C-CERAMIC,DISC 10nF,10%,50V,Y5P,12.5X4.0,5,TP
C803 2301-000016 C-FILM,PEF 22nF,5%,100V,7.2x4.5x9.0mm,5mm
C804 2401-000613 C-AL 1uF,20%,50V,WT,5x11mm,5mm,TP
C810 2305-000624 C-FILM,MPEF 330nF,10%,100V,5mm,TP
C811 2305-000624 C-FILM,MPEF 330nF,10%,100V,5mm,TP
C812 2305-000624 C-FILM,MPEF 330nF,10%,100V,5mm,TP
C813 2301-000184 C-FILM,PEF 1nF,10%,100V,5.3x10mm,5mm,TP
C814 2401-000613 C-AL 1uF,20%,50V,WT,5x11mm,5mm,TP
C815 2401-001334 C-AL 470nF,20%,50V,GP,5x11mm,2mm,TP
C816 2401-000310 C-AL 100uF,20%,25V,GP,8x11.5mm,3.5m
C820 2401-000042 C-AL 100uF,20%,16V,GP,6.3x7mm,2.5mm
C841 2301-000012 C-FILM,PEF 2.2nF,5%,100V,10.5x12.5x6.5,5m
C842 2301-000012 C-FILM,PEF 2.2nF,5%,100V,10.5x12.5x6.5,5m
C843 2301-000016 C-FILM,PEF 22nF,5%,100V,7.2x4.5x9.0mm,5mm
C844 2301-000016 C-FILM,PEF 22nF,5%,100V,7.2x4.5x9.0mm,5mm
C845 2301-000016 C-FILM,PEF 22nF,5%,100V,7.2x4.5x9.0mm,5mm
C846 2301-000016 C-FILM,PEF 22nF,5%,100V,7.2x4.5x9.0mm,5mm
C847 2301-000380 C-FILM,PEF 10nF,5%,50V,TP,6.5x3mm,5mm
C848 2301-000380 C-FILM,PEF 10nF,5%,50V,TP,6.5x3mm,5mm
C849 2301-000380 C-FILM,PEF 10nF,5%,50V,TP,6.5x3mm,5mm
C850 2301-000380 C-FILM,PEF 10nF,5%,50V,TP,6.5x3mm,5mm
CN801 3721-001006 PLUG-AC POWER 3P,10/24mm,SN
CN804 3711-000015 CONNECTOR-HEADER BOX,2P,1R,2.5mm,STRAIGHT,SN
CN805 3711-003942 CONNECTOR-HEADER BOX,2P,1R,2mm,STRAIGHT,SN
CN806 3711-003843 CONNECTOR-HEADER BOX,8P,1R,2mm,STRAIGHT,SN
CN806_CN841 BN39-40001C CBF-HARNESS 8P,110MM,BLU/RED/WHT,UL1007
CN808 3722-001009 JACK-PHONE 3P/2C,3.6PI,AG,BLK
CN809 3722-001009 JACK-PHONE 3P/2C,3.6PI,AG,BLK
CN810 3722-001101 JACK-USB 4P/2C,8.38mm,AU,IVR,#22-28
CN811 3722-001051 JACK-DIN 4P,5.12mm,AU,NTR
CN812 3722-001055 JACK-PHONE 5P/2C,3.6mm,AG,BLK,#16-22
CN813 3722-001055 JACK-PHONE 5P/2C,3.6mm,AG,BLK,#16-22
CN814 3711-003942 CONNECTOR-HEADER BOX,2P,1R,2mm,STRAIGHT,SN
CN815 3711-003942 CONNECTOR-HEADER BOX,2P,1R,2mm,STRAIGHT,SN
CN816 3711-000262 CONNECTOR-HEADER 1WALL,5P,1R,3.96mm,ANGLE,SN
CN841 3711-003846 CONNECTOR-HEADER BOX,8P,1R,2mm,ANGLE,SN
CN861 3711-001031 CONNECTOR-HEADER BOX,6P,1R,2.50mm,ANGLE,SN
CN862 3711-000058 CONNECTOR-HEADER BOX,4P,1R,2.5mm,ANGLE,SN
CN862_CN881 BN39-40001D CBF-HARNESS 4P,80MM,BLU/RED/WHT,UL1007,A
CN881 3711-000058 CONNECTOR-HEADER BOX,4P,1R,2.5mm,ANGLE,SN
CN882 BN39-40001F CBF-HARNESS 50MM,BLK,UL1015,AWG18,ST71
D801 0402-000016 DIODE-RECTIFIER UF5404,400V,3A,DO-201AD
D802 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,500mW,4nS,DO-
!
9 Electrical Parts List
SyncMaster 320TFT/520TFT 9-11
Loc. No. Code No. Description Specification Remarks
9-2 Sub PCB Parts
