IC803 1201-001269 IC-AUDIO AMP 4863,DIP,16P,300MIL,DUAL,PLA
IC804 1203-001161 IC-POSI.FIXED REG. 2576,TO-220,5P,PLASTIC,4.9/5
L801 BH27-20344D COIL-CHOKE 50UH,10%,DR8*8,TAPING
OP881 0601-001036 LED ROUND,GRN/YEL,4.75mm,565/585nm
Q802 0501-000586 TR-NPN,KSC945,TO-92,EBC 0.25W,60V,50V,5V,0.15A
R809 2001-000464 R-CARBON 2.4Kohm,5%,1/6W,AA,TP,1.8x3.2m
R810 2001-000043 REF-CF,1K,5%,1/6W 150V,-1300 TO +350PPM,R-AXIAL
R811 2001-000029 REF-CF,100,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
R812 2001-000029 REF-CF,100,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
R813 2001-000067 R-CARBON 10Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R814 2001-000059 R-CARBON 5.6Kohm,5%,1/6W,AA,TP,1.8x3.2m
R815 2001-000496 R-CARBON 20Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R816 2001-000484 R-CARBON 200Kohm,5%,1/6W,AA,TP,1.8x3.2m
R817 2001-000029 REF-CF,100,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
R818 2001-000496 R-CARBON 20Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R819 2001-000484 R-CARBON 200Kohm,5%,1/6W,AA,TP,1.8x3.2m
R820 2001-000029 REF-CF,100,5%,1/6W 150V,-1300 TO +350PPM/C,R-AXIAL
R821 2001-000086 R-CARBON 100Kohm,5%,1/6W,AA,TP,1.8x3.2m
R822 2001-000086 R-CARBON 100Kohm,5%,1/6W,AA,TP,1.8x3.2m
R841 2001-000040 R-CARBON 470ohm,5%,1/6W,AA,TP,1.8x3.2mm
R842 2001-000040 R-CARBON 470ohm,5%,1/6W,AA,TP,1.8x3.2mm
R843 2001-000496 R-CARBON 20Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R844 2001-000496 R-CARBON 20Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R845 2001-000059 R-CARBON 5.6Kohm,5%,1/6W,AA,TP,1.8x3.2m
R846 2001-000059 R-CARBON 5.6Kohm,5%,1/6W,AA,TP,1.8x3.2m
R861 2001-000067 R-CARBON 10Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R862 2001-000104 R-CARBON 1.2Kohm,5%,1/6W,AA,TP,1.8x3.2m
R863 2001-000104 R-CARBON 1.2Kohm,5%,1/6W,AA,TP,1.8x3.2m
R864 2001-000059 R-CARBON 5.6Kohm,5%,1/6W,AA,TP,1.8x3.2m
R865 2001-000069 R-CARBON 12Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R866 2001-000067 R-CARBON 10Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R867 2001-000562 R-CARBON 27Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R868 2001-000069 R-CARBON 12Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R869 2001-000051 R-CARBON 2.7Kohm,5%,1/6W,AA,TP,1.8x3.2m
R881 2001-000040 R-CARBON 470ohm,5%,1/6W,AA,TP,1.8x3.2mm
R882 2001-000404 R-CARBON 180ohm,5%,1/6W,AA,TP,1.8x3.2mm
SW841 3403-001048 SWITCH-PUSH 30V,100mA,DPDT,ON-OFF
SW861 3404-000243 SWITCH-TACT 15V,20mA,160gf+-50gf,6x3.4mm,S
SW862 3404-000243 SWITCH-TACT 15V,20mA,160gf+-50gf,6x3.4mm,S
SW863 3404-000243 SWITCH-TACT 15V,20mA,160gf+-50gf,6x3.4mm,S
SW864 3404-000243 SWITCH-TACT 15V,20mA,160gf+-50gf,6x3.4mm,S
SW865 3404-000243 SWITCH-TACT 15V,20mA,160gf+-50gf,6x3.4mm,S
SW866 3404-000243 SWITCH-TACT 15V,20mA,160gf+-50gf,6x3.4mm,S
SW881 3404-000243 SWITCH-TACT 15V,20mA,160gf+-50gf,6x3.4mm,S
VR841 2101-001040 VR-ROTARY 50Kohm,20%,1/30W,SIDE
VR842 2101-001041 VR-ROTARY 50Kohm,20%,1/20W,TOP
VR843 2101-001041 VR-ROTARY 50Kohm,20%,1/20W,TOP
9 Electrical Parts List
9-12 SyncMaster 320TFT/520TFT
Loc. No. Code No. Description Specification Remarks
