3. Floor mount guide
<Side view>
A : min. 50 mm
B: Ambient temperature Measuring point < 20°C
• When embedding the product in the floor, be sure there is a 50 mm space or more behind the product
for ventilation, as shown above, and maintain the ambient temperature at 20 °C or lower.
Note
A Samsung Electronics service center can provide details.
Mechanical Layout
(400MX-3, 400FP-3)
Introduction
