Note
• Press SOURCE
on the product or remote control and select "Component".
• Then, start the DVD Player with a DVD disc inserted.
• A RGB to component cable is optional.
• For an explanation of Component video, consult your DVD manual.
Connecting a DTV Set Top (Cable/Satellite) Box
Connect a RGB to Component cable between the [RGB/COMPONENT IN] port
on the LCD Display and the P
R
, Y, P
B
jacks on the Set Top Box.
Connect a set of audio cables between the [AV/COMPONENT AUDIO IN
[L-
AUDIO-R]] on the LCD Display and the AUDIO OUT jacks on the Set Top Box.
Note
• Press SOURCE
on the product or remote control and select "Component".
• For an explanation of Component video, see your Set Top Box owner's manual.
Connections
