12. Secure the USB cable to the dock with the USB clamp.
13. Mount the dock to the vehicle with the clamp. Position the tablet to face the driver, then tighten the mount clamp.
14. Use zip ties to secure loose cables.
Operation
NOTE: Refer to the Support site for operation instructions for applications and soware on the tablet.
System Check – Minimum Requirements
1. An installer must perform a full system check to verify the connection and operation of the tablet.
2. V4 System Check: Start vehicle engine and confirm the following LEDs:
Cellular Solid Green
GPS Solid Green or Orange
Status Solid Green
3. Power on the tablet and allow the device to boot up to the login screen:
a. Scan the Driver card or manually enter the Driver ID.
b. Enter the Driver PIN (Personal Identification Number).
4. Verify on-board SIM is active:
a. “No Service” should change to 3G/4G upon successful connection to a cell tower. This should take no more than one
minute.
b. Using the web browser, navigate to www.zonarsystems.com to test data connectivity.
NOTE: Some websites may be restricted due to Zonar Security Policies.
5. Connect to Wi-Fi® (Optional).
6. Make sure that all purchased application(s) are present on the tablet. They may include one or more of the
following applications:
ZLogs - Hours of Service application.
Navigation - Mapping and turn-by-turn direction application.
NOTE: Refer to the Support site for operation instructions for applications and soware on the tablet.
Operational Notes
Tablet requires a Zonar telematics box (V4) to operate.
