PCB Diagram
Samsung Electronics 101
䯴 EMI PCB
(AE090/120/160MXTPEH/EU)
This Document can not be used without Samsung’s authorization.
No.Local Function Description
1
L1 AC POWEROT-048
2 EARTH EARTH YEL/GRN WIRE
3L AC POWER BRN WIRE
4N AC POWER SKY/BLU WIRE
5N1 AC POWEROT-048
6 CN01 AC POWERYW396-03AV WHT
£
¤
¥
¦
§
¨
