PCB Diagram
102 Samsung Electronics
䯴 EMI PCB
(AE090/120/160MXTPGH/EU)
This Document can not be used without Samsung’s authorization.
No.Local Function Description
1
EARTH EARTH YEL/GRN WIRE
2 R-IN R-IN WHT WIRE
3 S-IN S-IN BRN WIRE
4 T-IN T-IN BLK WIRE
5 N-IN N-IN SKY/BLU WIRE
6 N-INV N-INV SKY/BLU WIRE
7T-INV T-INV BRN WIRE
8T-OUTT-OUT Y TR250
9 S-OUTS-OUT YTR250
10R-OUT R-OUT YTR250
11 CN01 AC POWERYW396-03AV WHT
£
¤
¥
¦
§
¨
©
