Disassembly and Reassembly
34 Samsung Electronics
No Parts Procedure Remark
9 CONTROL OUT 1) Disconnect the six connectors from the ASSY
CONTROL OUT.
2) Unscrew and remove the two screws on the
CONTROL OUT.
(Use '+' type screw driver)
3) Separate the ASSY CONTROL OUT
To Next Page
