Samsung TDM PLUS - Page 97

PCB Diagram
Samsung Electronics 97
No.Local Function Description
1
CN405 MID PRESSURE SENSOR SMW250-04 WHT
2 CN302 COMM-OPTION SMW200-05 BLK
3 CN402 HIGH PRESSURE SENSOR B04B-XARK-1 RED
4 CN401 LOW PRESSURE SENSOR B04B-XARK-1 BLU
5 CN305 COMM INV SMW250-06 WHT
6 CN801ERROR/C OMP CHECKSMW250-04 RED
7 CN805 EEV4 SMW250-05 BL U
8
CN12DC12V YW396-02V BLU
9 CN406SUCTION/D_TUBESMW250-04 YEL
10 CN001EXTERNAL CTRL SMW250-02 BLU
11 CN802 EEV1SMW250-06 BL U
12 CN306 DOWNLOAD YDW200-20 BLK
13 CN403 OUT/COND/DISCHARGE/OLP SMW250-08 WHT
14CN704 A2A VALVE YW396-03AV BLK
15CN702 4
WAY VALVE YW396-03AV YEL
16 CN701HOTGAS YW396-03AV RED
17 CN101 AC POWERYW396-03AV WHT
18 CN806EEPROM B7P-MQ WHT
19 CN304 DRED D APC-2009-6P BLK
20 CN501 MODE SELECTOR SMW250-03 WHT
21 CN103 EARTH YDW236-01 WHT
22 CN303 COMM-INDOOR YW396-02V RE
D
