7-13
▶ MODEL CODE: WF328AAW/XAA
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Location.No CODE-NO DESCRIPTION SPECIFICATION Un Q’TY SA/SNA
A0055 DC6
1-00219D CLIP-HOSE SK-5,SW-50A1S,ID33 OD35,MFZNT, PC 1 SNA
A0055 DC6
1-00219E CLIP-HOSE ID34,SK-5,OD37.2,ZPC2,- PC 1 SNA
H0075 DC3
1-00049A MOTOR BLDC-DRUM POM1300,0~1200,-,DC310V, PC 1 SA
I0043 DC67-00
126A HOSE-DRAIN GW-PJT,EPDM,OD 68,-,T2.0,-,BL PC 1 SA
I0046 DC67-00265A HOSE-DRAWER TUB MACH,EPDM,-,-,-,-,BLK,- PC
1 SA
I0078 DC67-00
124A HOSE-PRESSURE GW-PJT,EPDM,-,-,-,-,BLK,- PC 1 SA
N0008 DC6
1-70029C SPRING-CLIP SEW-HW125,HSWR67,CD1.2,ID8.5 PC 1 SA
N0010 DC65-00009A CLAMPER HOSE TS85-PJT,HSWR,-,-,YEL,OD24/ PC
1 SA
N0018 DC65-00014A CLAMPER HOSE GW-PJT,HSWR,-,ID82,ZPC2,HOS PC
1 SA
R0021 DC97-14728A ASSY G
UIDE-WATER FRONTIER II,PP,-,-,-,-,- PC 1 SA
R0001 DC97-12604B ASSY-DRUM SEW-HFR
179ATS,FRONTIER2MC-PJT PC 1 SA
R0002 DC66-0045
1A DRUM-FRONT ZEUS-PJT,STS430,-,OD582,ID400 PC 1 SNA
R0003 DC66-00485A DRUM-WRAPPER WF337AAR/XAA,STS430,-,OD56
1 PC 1 SNA
R0005 DC66-00452A DRUM-BACK ZEUS-PJT,STS430,-,OD582,ID58
1, PC 1 SNA
R0006 DC66-00453A DRUM-LIFTER ZEUS-PJT,PP(TI42),-,-,L3
14.2 PC 3 SA
R0007 DC97-
12528A ASSY-FLANGE SHAFT FRONTIER II,- PC 1 SNA
S0058 DC97-
12135A ASSY-BALANCER ZEUS-PJT,- PC 2 SNA
U0016 DC62-00156A SEAL-OIL TS85-PJT,NBR(SD45.5),BLK,-,-,- PC
1 SA
U0024 DC6
1-01450A TUB-BACK GW-PJT,FRPP(GF15%),PI 602,PI 6 PC 1 SNA
U0029 DC64-00802A DOOR-DIAPHRAGM GW-PJT,EPDM,T
1.5,-,-,-,GR PC 1 SA
U0038 DC97-0498
1D ASSY-CLAMP DIAPHGRAM WINGS-PJT,HSWR/ZPC4 PC 1 SA
U0078 DC97-
11526A ASSY-SEMI TUB BACK WF326LAS,HEATER/VENT- PC 1 SNA
U0079 DC97-08650F ASSY-SEMI TUB FRONT WF337AAW,
15%/HEATER/ PC 1 SA
U0086 DC67-00
139A WEIGHT-BALANCER(F) GW-PJT,GC,-,-,-,RED,F PC 2 SA
U0097 60
11-001548 BOLT-ETC M7.5,L30,ZPC(YEL),SWRCH18A,HEX PC 20 SA
U0112 DC61-01338B
BRACKET-HOUSING
BEARING
DR
130,SBHG1-A(GI PC 1 SA
U0133 DC66-00470A DAMPER-SHOCK FRONTIER II,STEEL+PP+RUBBER PC 2 SA
U0
133 DC66-00470A DAMPER-SHOCK FRONTIER II,STEEL+PP+RUBBER PC 2 SA
U0
185 DC67-00155A HOSE-O.F(I) WINGS-PJT,EPDM,-,-,T2.0,-,BL PC
1 SA
U0320 60
11-001556 BOLT-HEX M4,L60,ZPC3(WHT),SM10C,- PC 1 SNA
U0353 DC60-60044A WASHER-PLAIN -,ID
10.5,OD30,T3,-,STS304 PC 1 SA
U0353 DC60-60044A WASHER-PLAIN -,ID
10.5,OD30,T3,-,STS304 PC 2 SA
U0353 DC60-60044A WASHER-PLAIN -,ID
10.5,OD30,T3,-,STS304 PC 2 SA
U0354 603
1-001523 WASHER-WAVE SK5,-,ID35,OD45,T0.6,ZPC2,- PC 1 SA
U0358 DC47-00006G HEATER -,GW-PJT,STS3
16L,900W,7.18~7.8 PC 1 SA
U0359 DC6
1-01482A BRACKET-HEATER GW-PJT,STS430/304,T0.5,W9 PC 1 SA
U0362 DC60-60049A WASHER-SPRING -,ID
10.5,OD18,T2.5,-,SIR PC 1 SA
U0363 DC65-20008C CABLE CLAMP DA-8N,NYLON#66,-,-,NTR,ID
13. PC 1 SA
U0363 DC65-20008C CABLE CLAMP DA-8N,NYLON#66,-,-,NTR,ID
13. PC 2 SA
U0364 DC69-00804A PACKING-TUB GW-PJT,EPDM-FORM,-,PI8,W624, PC
1 SA
U0365 DC97-024
12A ASSY-BOLT SWF-P12,MOTOR, M8*L62 PC 4 SA
