10-4
Item Part No. Description
1 U3 Display the Course
2
IC1~3 Drive the LED & Display
Supply the Current to the Acting Current
3 U2 Rotary Switch (For the Selecting a Course)
4
LED & Key Input the Detail Course
Display the Resent Course
10-4. SUB PCB LAYOUT (THE PRINCIPLE PART)
To Next Page
