12 _ Removal and Reassembly
Part Figure Description
Separating the
Cover_Top and
Panel-Control
(Check Main-PCB
and Sub-PCB)
1. Removethe2hexagonscrews,whichareatthe
back,xingtheCOVER-TOP.
2. DisassembletheCOVER-TOPbyslidingit
backwardsandremovethe4screwsonthe
PANEL-CONTROL.
3. Withthetopcoverremovedyouwillnowhave
accesstoservicetheWaterpressuresensor,EMI
NoiseFilter,HotandColdWaterValves,Steam
ASSY,HoseDrawASSY,AndmainPCBASSY.
4. PresstheSeparatebuttontoseparatetheASSY
Drawer.
5. DisassembletheHOUSING-DRAWERfromethe
PANEL-CONTROL(pushbackandthenpush
Housing-drawerupsidetoseparate).
