Removal and Reassembly _ 13
Part Figure Description
Separating the
Cover_Top and
Panel-Control
(Check Main-PCB
and Sub-PCB)
6. PullthePANEL-CONTROLtowardsandthenliftit
upwardstoseparate.
7. Carefullydisconnectthethreewiringconnectorsby
hand.
592-493*AssyPanelControl
592-493*AssyPanelControl
8. RemovetheallscrewsholdingthePCBand
releasethehooksonbothsidestoremovethe
PCBforrepair/replacement.
