Removal and Reassembly _ 15
Part Figure Description
Disassembling and
Reassembling the
Door Part
1. Removethe2screwsholdingtheHINGE-DOOR
andtheFRAME-FRONT.
2. DisassembletheASSYDOORliftingitupslightly.
3. Removethe10screwsxingtheHOLDER-
GLASS.
(includingthe2bluescrewsholdingtheLEVER-
DOOR,includingthe3arrowscrewsholdingthe
HINGE-DOOR.)
4. Puttingandpressinghardaat-headscrewdriver
intothefurrowbetweenCOVER-DOORand
SUPPORT-HINGE.
5. Makingasemicirclewithscrewdriver.
(Disassemblethehooks)
6. DisassembletheHOLDER-GLASSfromCOVER-
DOORTaketheDOOR-GLASS,SUPPORT-
HINGE,HINGE-DOOR.
* CheckPointsforTroubleshooting
• CheckthestatusofthescrewsholdingtheHinge(checkiftheyareloose).
Checkifthefrontandrearofthedoorandthehingepartarenotdamaged.
