S&C 6800 Series User Manual

Switch Control Setup
Important: For any one team, the values must be identical in all team members
except for the Comm Port to Use setting.
Each team screen includes the following fields:
Team ID
Enter the name of this team, 16 characters maximum. This name will help identify the
team to the SCADA operator. It appears on all reports generated from the team members.
When saving a team conguration, this name is saved along with the other information.
It also appears on the front panel display, if applicable.
Team Logic
This setpoint enables or disables the IntelliTeam II system or sets various IntelliTeam
SG system feature options for this team.
Set Team
This setpoint changes the operation status of the team dened on this screen. When team
logic detects any parameter changes on this screen, the setpoint automatically changes
to the Stopped status.
Important: When this value is set to the Stopped mode and then back to the
Running mode, IntelliLink software uses the setpoint values on this screen as the pres-
ently valid team parameters. Until all team members have identical values on this screen,
the team will not be in the Ready state.
Alternate Source Sequence
Prioritize the way team members restore a line segment. If the team cannot use the
source device (see Normal Sw Func) to restore the line segment, the team will try the
members listed here, in the order congured.
The alternate source sequence is optional and does not need to be configured for
automatic load restoration to occur. If this information is not entered or if the selected
team members cannot be used to restore the line segment, the team will try to restore
the line segment with the tie device(es). If this is not successful, the team will try to
restore the line segment using the load/tie device(es).
General Team Parameters
These setpoints apply to the entire team.
Line Segment Limit
Congure this to the maximum number of line segments the team can pick up. For
example, the Add 1 setting inhibits additional line segments from being restored through
a member after the team restores one line segment. To allow the team to pick up as many
line segments as capacity allows, set this value to the N/A setting.
Contracts will be used if the Line Segment Limit threshold is set. Configuring
this setpoint to a value other than an N/A setting automatically changes the Contract
Required setpoint to a Yes setting.
Contract Required
If there is concern a line segment may overload, set this value to a Yes setting. As team
members encounter such line segments in a restoration path, they will communicate
with all the other line segments in the direction of the alternate source to ensure the
alternate source will not be overloaded.
Team Load Priority
This is user congurable, and the default is the NoXfer setting. The choices are:
Priority1_NoXfer—Load shedding or transferring is not allowed.
Priority2_CloseXfer—Load shedding is not allowed. Load transfer is allowed through
closed transition only.
52 S&C Instruction Sheet 1045-530
