S&C ELECTRIC COMPANY
s
INSTRUCTION SHEET
663-503
Page 33 of 35
August 14, 1995
ACCESSORIES
Item Catalog Number
S&C Test Accessory, permits preliminary checkout of source-transfer control using single-phase 120-volt ac source (before
medium-voltage connections are made to the pad-mounted gear) to expedite full service once medium voltage is available. The test
accessory isolates the S&C Voltage Sensor during testing and eliminates the possibility of backfeed during test procedures
TA-1316
Portable Remote-Control Station with 50-foot cord, connects to one remote-control receptacle (not included; see optional feature
“-C11” on page 31) to permit open/close operations from an adjacent location
5294
Maintenance Cable, for connecting Micro-AT control communications card (see optional
feature “-Y8” on page 32) to user-furnished personal computer
For personal computers having 25-pin
serial communication port
TA-2320
For personal computers having 9-pin
serial communication port
TA-2321
Grounding Jumpers, set of three, with eye-type clamps for installation with a standard
shotgun clamp stick
3 cable length 4210
Shotgun Clamp Sticks for installation of grounding jumpers and for use with voltage
testers
65¹⁄₂
length 9933-150
85¹⁄₂
length 9933-151
Storage Bag, heavy canvas
For grounding jumpers 9933-149
For shotgun
clamp stick
66 length 9933-152
86 length 9933-153
Voltage Tester with audio and visual signals, includes voltage tester, batteries, adapter for shotgun clamp sticks, and storage case
1
9931-072
Pentahead Socket, for ¹⁄₂ -inch drive 9931-074
1
For ultimate users other than electric utilities, also specify a shotgun
clamp stick of the appropriate length.
APPENDIX D — Continued
