APPENDIX E
Current-Limiting Fuses for Use in
S&C PMH Pad-Mounted Gear
Types Accommodated and Adapters Required
S&C Holders for current-limiting fuses are designed for
use in pad-mounted gear models that include mountings
for Fault Fiter Electronic Power Fuses. In PMH Pad-
Mounted Gear, these holders will accommodate the
single-barrel current-limiting fuses listed in the table
below when the fuses are equipped with ⁵⁄₈-inch diameter
mounting studs at both ends. Depending on the length and
diameter of the current-limiting fuse to be used, adapters
may be required in order to fit the fuse in the holder.
Adapters, when required, are furnished with the S&C
Holder and are signified by a suffix to the catalog number
of the holder. For instructions on installing current-limit-
ing fuses in S&C Holders, refer to S&C Instruction Sheet
660-500.
CURRENT-LIMITING FUSES—Types Accommodated and S&C Holders Required
For use in
PMH Models
Rated, Kv
Current-Limiting Fuse
1
S&C Holder
3
Manufacturer Type
Rating
2
Catalog Number
4
Max, Kv Max Amperes, Rms
14.4
Kearney
B 8.3 30—112 3142-A1
Q
8.3
8.3
15.5
15.5
15.5
6—30
40—100
6—30
40—50
65—100
3142-A3
3142-A1
3142-A2
3142-A1
3142
Cooper Power Systems
McGraw-Edison
NX
®
8.3
8.3
15.5
15.5
1.5C—40C
50C—100C
1.5C—40C
1.5C—100C
3142-A3
3142-A1
3142-A2
3142
RTE
®
ELX
8.3
15.5
3—50
3—50
3142-A3
3142-A2
Westinghouse CX
8.3
15.5
3.5C—40C
4C—40C
3142-A3
3142-A2
Combined
Technologies, Inc.
X Limiter™
8.3
8.3
15.5
15.5
12—40
50—140
12—40
50—100
3142-A3
3142-A1
3142-A2
3142
25
Kearney
B
15.5
22
30—100
25—65
3143R1-A1
3143R1-A1
Q
15.5
15.5
6—30
40—100
3143R1-A3
3143R1-A1
Cooper Power Systems
McGraw-Edison
NX
®
15.5
15.5
23
1.5C—40C
50C—100C
6C—40C
3143R1-A3
3143R1-A1
3143R1-A3
RTE
®
ELX
15.5
23
3—50
3—40
3143R1-A3
3143R1-A3
Westinghouse
CX 15.5 4C—40C 3143R1-A3
CXN 15.5 45C—60C 3143R1-A1
Combined
Technologies, Inc.
X Limiter™
15.5
15.5
23
12—40
50—100
12—40
3143R1-A3
3143R1-A1
3143R1-A3
1
The single-barrel current-limiting fuses listed in this table are to be
purchased from the appropriate current-limiting fuse manufacturer.
2
The maximum voltage and maximum ampere ratings listed in this
table apply when the corresponding current-limiting fuse is used. Con-
sult the appropriate current-limiting fuse manufacturer for complete fuse
ratings.
3
S&C Holders for use in 14.4-kv models of PMH Pad-Mounted Gear are
rated 14.4 kv nominal, 17.0 kv maximum, and 200 amperes maximum.
S&C Holders for use in 25-kv models of PMH Pad-Mounted Gear are rated
25 kv nominal, 29 kv maximum, and 200 amperes maximum.
4
Includes adapters when required.
