S&C Vista SD - Appendix C; Switchgear Styles and Models

S&C Instruction Sheet 695-510 29
Appendix C
Table 7. Switchgear Styles—Must be Specified
Item
Suffix to be Added to
Switchgear
Catalog Number
Applicable to Models
Vault-mounted style. Where
switchgear assembly is floor-
mounted. Includes submersible
wiring and control housing
①
Vertical orientation, cables
enter/exit from top, operating
mechanism on bottom
Mild steel
mounting stand
-V1
110, 101
303, 312, 321, 330
404, 413, 422, 431, 440
505, 514, 523, 532, 541, 550
606, 615, 624, 633, 642, 651, 660
Stainless steel
mounting stand
-V11
110, 101
303, 312, 321, 330
404, 413, 422, 431, 440
505, 514, 523, 532, 541, 550
606, 615, 624, 633, 642, 651, 660
Vertical orientation, cables
enter/exit from bottom,
operating mechanism on top
Mild steel
mounting stand
-V2
110, 101
303, 312, 321, 330
404, 413, 422, 431, 440
505, 514, 523, 532, 541, 550
606, 615, 624, 633, 642, 651, 660
Stainless steel
mounting stand
-V12
110, 101
303, 312, 321, 330
404, 413, 422, 431, 440
505, 514, 523, 532, 541, 550
606, 615, 624, 633, 642, 651, 660
Horizontal orientation, cables
enter/exit from sides
Mild steel
mounting stand
-V3 110, 101
Stainless steel
mounting stand
-V13 110, 101
Pad-mounted-style. Includes
pad-mounted style enclosure
with olive green outdoor finish.
Single-sided access facilitates
installation adjacent to wall or
other structure
Mild steel enclosure -P1
210, 201
303, 312, 321, 330
404, 413, 422, 431, 440
505, 514, 523, 532, 541, 550
606, 615, 624, 633, 642, 651, 660
Stainless steel enclosure -P11
210, 201
303, 312, 321, 330
404, 413, 422, 431, 440
505, 514, 523, 532, 541, 550
606, 615, 624, 633, 642, 651, 660
①
For wall-mounted applications, refer to your nearest S&C Sales office.
