S&C Vista SD - Pad-Mounted Style

S&C Instruction Sheet 695-510 7
Location of Safety Labels and Tags
Reorder Information for Safety Labels
Location Safety Alert Message Description Number
A
DANGER
Keep Away–Hazardous Voltage (“Mr. Ouch”) G-6699
B
DANGER
Hazardous Voltage–Always Consider Circuits and Components
Live...
G-6700
C
WARNING
Do Not Block Pressure-Relief Device (not visible) G-6742
D
WARNING
Before Using Voltage Tester–Always Test for Proper Operation G-9451
E
WARNING
Keep Out–Hazardous Voltage Inside G-6398
Figure 3. Location of Safety Labels — Model 321 (3-way) pad-mounted style unit shown.
E E
WARNING
KEEP OUT
Hazardous voltage inside.
Can shock, burn, or cause
death.
If open or unlocked,
immediately call electric
company.
G-6398
Safety Information
A
B
A
B
D
NOTE: The Installation and Operation
Information Kit is stored in a slot behind
the manual operating handle to the left
of Way 1. Designate a location where
you can easily retrieve it and refer to it.
Padlock
