S&C Vista SD - Multi-Way Vault-Mounted Style

6 S&C Instruction Sheet 695-510
Location of Safety Labels and Tags
Reorder Information for Safety Labels
Location Safety Alert Message Description Number
A
DANGER
Keep Away–Hazardous Voltage (“Mr. Ouch”) G-6699
B
DANGER
Hazardous Voltage–Always Consider Circuits and Components
Live...
G-6700
C
WARNING
Do Not Block Pressure-Relief Device (not visible) G-6742
D
WARNING
Before Using Voltage Tester–Always Test for Proper Operation G-9451
Figure 2. Location of Safety Labels — Model 321 (3-way) vault-mounted style unit shown.
C
B
A
D
Safety Information
NOTE: The Installation and Operation
Information Kit is taped to the switchgear
assembly. Designate a location where you
can easily retrieve it and refer to it.
NOTE: The manual operating handle
is stored on a mounting stand (not
visible).
