S&C Vista - Location of Safety Labels

Safety Information
S&C Instruction Sheet 682-510 5
Top of switchgear
Pad-mounted enclosure
Reorder Information for Safety Labels
Location Safety-Alert Message Description Part Number
A
WARNING
Keep Out—Hazardous Voltage Inside
G-6681
B
DANGER
Hazardous Voltage—Always Consider Circuits and Components Live � � �
G-6700
C
DANGER
Never Drill Into Tank—Hazardous Voltage, Contains Pressurized Gas
G-6682
D
DANGER
Keep Away—Hazardous Voltage (“Mr� Ouch”)
G-6699
E
WARNING
Check Gas Pressure Before Operating Switchgear
G-6686
F
WARNING
Always Test Voltage Indicator For Proper Operation
G-6689
G●
WARNING
Always Visually Confirm Blade Position
G-6693
G-6694 (option “-L2”)
●
This label is located on the side of the gear and is not visible in this photo�
A
B
C D
E F
G ●
Location of Safety Labels
