1 • Model SA1/SA25
Explanation of Pump Nomenclature
ATEX Detail
Wet End Materials
B Nitrile
N Neoprene
R Hytrel
S Santoprene
V FKM
E EPDM
Design Level
5
Construction
A Aluminum Wetted, Aluminum Air
SI Stainless Steel Wetted, Cast Iron Air
SS Stainless Steel Wetted, Aluminum Air
Pump Series
S SANDPIPER
®
Pump Design
A Flap
Pump Size
1 1"
25 1" BSPT (Tapered Thread)
Discharge Porting Position
D Bottom
ET Dual Top
T Top
ED Dual Bottom
Options
P1 Intrinsically Safe ATEX Compliant
Pulse Output
Your Serial #: (ll in from pump nameplate) _____________________________________
__ __ _____ __ ___ __ __
Pump Pump Pump Size Discharge Diaphragm/ Design
Construction
Series Design and Options Porting Valve Level
XX X XXXXXX, XX XXX X XX
Model #:
(ll in from pump
nameplate)
Your Model #:
HDF1
ATEX Detail Construction Options
HDB1½, ST1½
ATEX Detail Construction Options
HDB2, SB1, SA1
ATEX Detail
Construction Options
II 1G c T5
II 1D c T100°C
I M1 c
I M2 c
SI, HI
II 2G c T5
II 2D c T100°C
A, SI, SS, HC, HI
II 2G Ex ia c IIC T5
II 2D Ex c iaD 20 IP67 T100°C
A, HC, HI, SI, SS
00
II 2G Ex ia c IIC T5
II 2D Ex c iaD 20 IP67 T100°C
A, HC, HI, I, II, SI, SS P1
II 1G c T5
II 1D c T100°C
I M1 c
I M2 c
II, SI, HI
P1
II 1G c T5
II 1D c T100°C
I M1 c
I M2 c
II, SI, HI N/A
II 2G c T5
II 2D c T100°C
A, CI, II, HI, HC, SI, SS N/A
00
II 2G c T5
II 2D c T100°C
A, HC, I, SI, SS
00
00
MODEL SPECIFIC
1: PUMP SPECS
