Installation in a Double-Hung or Sliding Sash Window
1. Cut the sealing foam (adhesive one) to the
proper length and attach it to the window
stool (double-hung) or window frame
(sliding).
2. Adjust the length of the window slider kit
according to the window, then attach it to
the window stool (double-hung) or window
frame (sliding).
Foam seal
(non adhesive)
Bracket
Adhesive long
foam seal
Adhesive
foam seal
foam seal
Adhesive
foam seal
Window slider
Foam seal (non adhesive)
Bracket
Window slider
or
Double-hung
window
Sliding sash
window
3. Cut the other sealing foam (non-adhesive) to
the proper length. Insert the seal between
the glass and the window frame to prevent
air and insects from entering the house.
4. Install the security bracket with the 2
screws to x the window (optional).
5. Insert the window slider adapter into the
hole of the window slider.
