Installing the Exhaust Hose
Window Installation
Window Slider Kit Installation
It may be necessary to adjust the length of the
window slider kit in order to t your window.
Never cut out the hole in the window slider kit.
You can use the window slider kit plug to x the
window slider kit after adjustment.
1. Assemble the exhaust hose with the exhaust hose adapters.
Exhaust Hose Adapter
(connected with Main Unit)
Exhaust Hose Adapter
(connected with
Window Slider)
Exhaust Hose
2. Install the exhaust hose assembly to the
main unit.
Window slider kit
