24
GB
INSTALLATION
11. Re-attach top hinge bracket to where they was located on
the opposite side (right to left).
8. Unscrew and remove the lower hinge bracket. Unscrew the
levelling feet and place it to opposite side.
9. Place the two screws, the bottom bracket and the levelling
feet to one side.
10. Lift the door and place it on a padded surface to prevent
scratching it.
4. Remove the decorated caps on the glass door.
5. Unscrew the two screws that hold the door handle and then
transfer the handle other side.
6. Place the decorated caps back to glass door.
7. Tilt the unit carefully. 2 people are required to tilt the unit
during the door reversing process.
12. Set the door back on to the top hinge. Screw the bottom
hinge into place on the new side. Also screw in the levelling
foot.
SWC32B11E_7L_IB_130521_Shaun.indb 24 21/05/2013 12:19 PM
