5.2 Technical Information PRO LINE
CPU Intel® Haswell ULT i5-4300U Option: Intel® Broadwell ULT i5-5350U
Memory 4GB DDR3 SO-DIMM 4GB DDR3 SO-DIMM
BIOS AMI uEFI BIOS AMI uEFI BIOS
Hardware Monitor Temperature, Voltages Temperature, Voltages
Watchdog
Programmable WDT to generate System reset
event
Programmable WDT to generate System reset event
RTC Processor integrated RTC Processor integrated RTC
I/O Standard
3x GbE (2x Intel® I210, 1x Intel® I218-LM), 2x
Display Port, 4x USB3.0
3x GbE (2x Intel® I210, 1x Intel® I218-LM), 2x
Display Port, 4x USB3.0
Power Supply
12-30VDC Input via Phoenix Connector PSC
1,5/3-F
12-30VDC Input via Phoenix Connector PSC 1,5/3-F
Cooling Fanless passive cooling Fanless passive cooling
Operating Temperature 0°C - 50°C ambient (UL listed 0°C - 45°C) (**) 0°C - 50°C ambient (UL listed 0°C - 45°C) (**)
Operating Altitude
Up to 3000m (9900 ft) Up to 3000m (9900 ft)
Storage Altitude
Up to 5000m (16500 ft) Up to 5000m (16500 ft)
Humidity 10%-90% @ 39°C, non condensing 10%-90% @ 39°C, non condensing
OS Support
Windows7 incl Embedded, Windows8.1 Pro,
Windows10 IoT, Linux Ubuntu
Windows7 incl Embedded, Windows8.1 incl
Embedded, Linux, Windows10
IoT
Certification CE, cULus, Design to meet FCC CE
Protection class Front: IP65, Housing IP20 Front: IP65, Housing IP20
EMC EN55022 class B EN55022 class B
Options
(Further options on request)
8GB RAM
CF/SD Card Adapter
SD Card Memory 4GB, 16GB, 32GB, 64GB
mSATA SSD 32GB, 64GB, 128GB, 256GB, 512GB
2x COM (RS232, RS422, RS485)
Audio with amplifier (2x 3W)
CF Card Memory ,
RFID, WiFi (on demand)
8GB RAM
CF/SD Card Adapter
SD Card Memory 4GB, 16GB, 32GB, 64GB
mSATA SSD 32GB, 64GB, 128GB, 256Gb, 512GB
2x COM (RS232, RS422, RS485)
Audio with amplifier (2x 3W)
CF Card Memory ,
RFID, WiFi (on demand)
(** except panel pc in size 23.8“: operating temperature 0-45°C ambient)
CPU Intel® Skylake ULT Core™ i5-6300U Intel® Kaby Lake ULT Core™ i5-7300U
Memory 4GB DDR4 SO-DIMM 4GB DDR4 SO-DIMM
BIOS AMI uEFI BIOS AMI uEFI BIOS
Hardware Monitor Temperature, Voltages Temperature, Voltages
Watchdog
Programmable WDT to generate System reset
event
Programmable WDT to generate System reset event
RTC Processor integrated RTC Processor integrated RTC
I/O Standard
3x GbE (2x Intel® I210, 1x Intel® I218-LM), 2x
Display Port, 4x USB3.0
3x GbE (2x Intel® I210, 1x Intel® I218-LM), 2x
Display Port, 4x USB3.0
Power Supply
12-30VDC Input via Phoenix Connector PSC
1,5/3-F
12-30VDC Input via Phoenix Connector PSC 1,5/3-F
Cooling Fanless passive cooling Fanless passive cooling
Operating Temperature 0°C - 50°C ambient (UL listed 0°C - 45°C) (**) 0°C - 50°C ambient (UL listed 0°C - 45°C) (**)
Operating Altitude
Up to 3000m (9900 ft) Up to 3000m (9900 ft)
Storage Altitude
Up to 5000m (16500 ft) Up to 5000m (16500 ft)
Humidity 10%-90% @ 39°C, non condensing 10%-90% @ 39°C, non condensing
OS Support
Windows7 incl Embedded,
Windows10 IoT, Linux Ubuntu
Windows10 IoT, Linux Ubuntu
Certification CE, cULus, Design to meet FCC CE, cULus, Design to meet FCC
Protection class Front: IP65, Housing IP20 Front: IP65, Housing IP20
EMC EN55022 class B EN55022 class B
Options
(Further options on request)
8GB or 16GB RAM
M.2 SSD 64GB, 128GB, 256GB, 512GB
2x COM (RS232, RS422, RS485)
Audio with amplifier (2x 3W)
RFID, WiFi (on demand)
8GB or 16GB RAM
M.2 SSD 64GB, 128GB, 256GB, 512GB
2x COM (RS232, RS422, RS485)
Audio with amplifier (2x 3W)
RFID, WiFi (on demand)
