7 Product Description
7.1 Product view
7.1.1 Front View Description
fig. 2: Front view
7.1.2 Rear View Description – full metal-variant
fig. 3: Rear view
TFT Display with resitive
or P-CAP Touch front
Front plate
RFID sign (option!)
Rear cover
Peripherie Backside,
description s. chapter 9
Holes for VESA mounting (full-metal-variant only!)
