SANJIANG SEC1000 - Installation and Connections; Panels Interior

SEC1000 FIRE ALARM CONTROL PANEL
Page
3
of 24
Recommended type of cable
Plain unscreened cable, 1.5mm
2
Cable diameter
1mm
2
~ 2.5mm
2
Transmission distance
≤1500m
FAULT OUT
(COM, NO)
Contact capacity
30VDC@2A, 125VAC@0.5A
Recommended type of cable
Plain unscreened cable, 1.5mm
2
Cable diameter
1mm
2
~ 2.5mm
2
24VK (+, -)
Output voltage
20 ~ 28VDC
Max. output current
500mA, 1A S.C.Out+24VK in total
Recommended type of cable
Plain unscreened cable, 1.5mm
2
Cable diameter
1mm
2
~ 2.5mm
2
Loop
LOOP OUT (+, -)
LOOP IN (+, -)
Output voltage
18.5 ~ 28VDC, pulse
Max. output current
500mA
Loop type
Class A and Class B
Recommended type of cable
Unscreened twisted-pair, 1.5mm
2
Max. Loop length
2000m
Cable diameter
1mm
2
~ 2.5mm
2
Network communication
RS-485
Transmission rate
9600 bps
Recommended type of cable
Unscreened twisted-pair, 1mm
2
Transmission distance
≤1000m
Cable diameter
1mm
2
~2.5mm
2
CAN
Max. number of panels
20
Transmission rate
Optional: 10K, 20K, 50K and 100K bps
Recommended type of cable
Unscreened twisted-pair, 1mm
2
Transmission distance
≤1000m
Cable diameter
1mm
2
~ 2.5mm
2
Physical dimensions
Approx. Dimensions of the panel (W×H×D)
400×360×104mm
Approx. weight (without battery)
3.7kg
Operating conditions
Temperature range: -5°C~ 45°C; Max relative humidity: 95% (40°C ± 2°C, no condensation)
3. Installation and Connections
The panel is supplied with a plastic detachable exterior door and front panel for operation and
display, a mental back box and functional PCBs. Space is available inside the panel for the
rated capacity of VRLA backup batteries, an optional communication board if applicable.
3.1 Panel’s interior
The interior can be accessed by the key of the front panel provided.
