3- Illustration of the interface panel
(1) Illustration of control board
ITEM DESCRIPTION
1 IR & LED
Infrared Receiver. (IR)
The LED light indicates when the LCD TV is activated.
2 Power Switch
AC power on/off.
3 VOL+
Adjusts the volume up.
4 VOL-
Adjusts the volume down.
5 CH∧
Scans up through channels.
Selects sub-menu items on the OSD mode.
6 CH∨
Scans down through channels.
Selects sub-menu items on the OSD mode.
7 MENU
Displays the OSD menu (on screen display).
8 SOURCE
Chooses from different input signal sources.
9 POWER
Turns the LCD TV on and off.
①
②
V
OL
+
-
∧
∨
CH
③
④
⑤
⑥
⑦
⑨
⑧
