2.
OPERATIONS
A
static-mode
digital
tuning
system
has
been
used
for
the
tuner
sec-
tions
of
Model
9900Z,
8900ZDB,
and
7900Z.
The
system
comprises
a
Pre-scaler
1C/TD6104P,
PLL
synthesizer
control
IC/TC9140P
and
a
digital
display
driver
1C/TD6301P.
2-1.
Main
Function
A.
Function
of
Tuning
Selection
1)
In
9900Z
and
8900ZDB,
a
rotary
encoder
is
adopted
to
realize
a
novel
manual
tuning
system,
in-which
the
conventional
analog
tuning
system
and
digital
tuning
system
are
used
together.
2)
In
7900Z,
one-step/one-push,
manual
tuning,
fast
forward
manual
tuning,
and
automatic
search
tuning
can
be
made
by
depressing
the
AUTO/MANUAL
selection
switch
and
the
UP/
DOWN
key
which
are
joined
with
each
other.
3)
The
memory
can
write-in
or
read-out
six
FM
broadcasting
sta-
tions
and
six
AM
broadcasting
station,
respectively,
by
pushing
the
MEMORY
key
(f$101)
and
the
PRESET
keys
(fS102-fS107).
B.
Display
of
Received
Frequency
The
received
frequency
can
be
displayed
in
two
methods,
simultane-
ously:
analog
dial
display
by
LEDs
and
digital
display
by
IC/
TD6301P.
C.
Others
Upon
the
operations
of
the
PRESET
keys,
FM/AM
band
selection,
and
scanning,
an
approx.
2.5
kHz
pulse
signal!
(as
shown
in
Fig.
2-1)
is
outputted
for
a
fixed
period
from
the
terminal
“Pee’’
of
TC9140P,
so
as
to
produce
an
operation-confirming
pitch
sound
from
the
buzzer
(fSP1).
L-CH
OUT
Signal,
Tune
Drive
Circuit
sits:
2~*
SIGNAL
oomoa
AM
9
j7]/7
77
KHE
tune
wea
FM
/
LILI
mi
Fig.
2-1
FM/AM
band
Selection,Memory
read-out,Manual
UP/DOWN
Manual
fast
forward,
Automatic
scanning
2-2.
Operation
of
Manual
Tuning
in
9900Z
and
8900ZDB
In
9900Z
and
8900ZDB,
the
manual
tuning
is
performed
by
the
use
of
a
rotary
encoder
including
two
photo-couplers,
without
depress-
ing
the
UP/
DOWN
key.
The
photo-couplers
and
a
reflector
mounted
on
the
tuning
knob
de-
tect
whether
the
tuning
knob
is
being
rotated
clockwise
to
increase
(UP)
the
frequency
or
counterclockwise
to
decrease
(DOWN)
the
frequency
to
be
received.
The
two
photo-couplers
fPH51
and
fPH52
detect
the
respective
positions
with
a
phase
difference
of
90
degrees.
Fig.
2-2
(a)
shows
a
mutual
relationship
between
two
output
pulses
of
fPH51
and
fPH52,
when
the
tuning
knob
is
being
clockwise;
(b)
shows
a
mutual
rela-
tionship
between
two
output
pulses
of
fPH51
and
fPH52,
when
the
tuning
knob
is
being
rotated
counterclockwise.
The
two
output
pulses
are
converted
into
an
UP
or
DOWN
pulse
signal,
respectively,
through
a
pulse
generator
circuit
as
shown
in
Fig.
2-3,
and
next
fed
to
the
terminal
UP
or
DOWN
of
TC9140P
in
order
to
increase
(UP)
or
decrease
(DOWN)
the
frequency
to
be
received.
:
