Parts No. Stock No. Description
: dLi 07196400 Low Pass Filter
dL2 07196400 Low Pass Filter
dT1 42359300 FM iF COIL (10.7 MHz)
‘ : dT2 42362300 FM iF COIL
' dT3 42362400 FM IF COIL
: dVR1 07241200 Semi Variable Resistor 5 kQ (B)
dVR2 07241600 Semi Variable Resistor
100 k& (B)
dVR3 07241200 Semi Variable Resistor 5 k (B)
dVR4 07241200 Semi Variable Resisotr 5 kQ (B)
dVR5 07241300 Semi Variable Resistor
10 kQ (B)
dS1 07251100 Slide Switch
e@ 7900Z
Parts No. Stock No. Description
07113200 FM Frontend Pack FD216U18
eTransistor
dQ1 03063401,2 2SC1674 L,K
dQ4 03059501 2Ssc945 Q
07194800,1 2SC1815 Y,GR
das 03059501 2S8c945 Q
‘
07194800,1
2SC1815
Y,GR
dQ6 ~—07197001 2SA733A Q
;
07194700,1
2SA1015
Y,GR
dQ7 07197001 2SA733A Q
|
-07194700,1
2SA1015
Y,GR
i das 07197001 2SA733A Q
; 07194700,1 2SA1015 Y,GR
: dag 03059501 2Ssc945 Q
i 07194800,1 2SC1815 Y,GR
' dQ10 03059501 2sc945 a
: 07194800,1 2SC1815 Y,GR
dot 03059501 28c945 OQ
07194800,1 2SC1815 Y,GR
' dQ12 03059501 2sc945 Q
: 07194800,1 2SC1815 Y,GR’
daQi3 07197001 2SA733A Q
07194700,1 2SA1015 Y,GR
dQi5 03059501 ~ 3 2SC945 Q,P,K
dQ16 03059501 ~ 3 2SC945 QO,P,K
daig9 03059501 2sc945 QO
07194800,1 2SC1815 Y,GR
dQ20 07197001 2SA733A QO
07194700,1 2SA1015 Y,GR
dQ21 03059501 28c945 Q
07194800,1 2SC1815 Y,GR
elc Nake
dict 03605900 TA7302P
dIC2 03609300 HA11225
: dic3 03606800 HA11223W
: dic4 03609500 MSM4001 RS
' 03610500 TC40018P
‘ eDiode
dD1~9 03117600 1$2473D
dc45 08450200 22uF 6.3V E.B.
dCF1 07264900 Ceramic Filter
dl1 07196400 Low Pass Filter
dt2 07196400 Low Pass Filter
daT1 42359300 FM IF Coil
dT2 42362300 FM IF Coil
dT3 42362400 FM IF Coil
dVRi1 07241200 Semi Variable Resistor 5 kQ (B)
dVR2 07241600 Semi Variable Resistor
100 kf (B)
dVR3 07241200 Semi Variable Resistor 5 kQ (B)
dVR4 07241200 Semi Variable Resistor 5 kQ {B)
dVR5 07241300 Semi Variable Resistor
10 kQ (B}
Parts No. Stock No. Description
dS1 07251100 Slide Switch
eTransistor
eQ1~4 07194800,1 2SC1815 Y,GR
e05 03059501,2 2S8C945 Q,P
eic
elC1 07237200 LA1245
eD1 07197200 Varactor Diode KV1226
eDiode
eD3,4 03117600 1$2473D
eTC1,2 12301000 Trimmer Capacitor 15pF
eCF1 07254000 Ceramic Filter
eCF2 07265100 Ceramic Filter
eL1 46027100 AM OSC Coil
eL2 42306200 AM IF Coil 455 kHz
eVR1 07241300 Semi Variable Resistor
10 k& (B)
eVR2 07241500 Semi Variable Resistor
50 kQ (B)
1-14. F-3309 Power Supply Circuit Board
e@ 9900Z
Parts No. Stock No. Description
eTransistor
mQ1 03085201,2 280438 E,F
mQ2 03084801,2 2S0358 D,E
mQ3 03084302,3 2SD381 L,K
mQ4 03084302,3 2SD381 L,K
mQs 03084302,3 2SD381 L,K
Diode
mO1 03116700 SS-7
mD2 03116800 SS-7R
mD3 03117000 RB-152
e@Zener Diode
mDZ1 03172100 RD3OF B
mDZ2 03172100 RD3OF B
mDZ3 03164700 RD20E B
mDZ4 03164100 RD6.8E B
mDZ5 03163300 RDi5E B
mDZ6. 07181500 RD22E B
mR1 00105900 1kQ SW CLR.
mR2 00194500 18kQ2 W NLA.
mR17 00181200 2202 1W N.I.R.
mR18 00187500 18k2 2W N.LR.
mR19 00188900 332 2W N.ILR.
mC2 00380500 109000pF 500V C.C.
mc3 00380500 10000pF 500V C.C.
mC4 00380500 10000pF 500V C.C.
mC5 00380500 10000pF 500V C.C.
PC1 00386100 4700pF 150V C.C.
00386500 4700pF 125V C.C.
pF1 04341000 Fuse 12A 125V (100V ~ 120V)
04323000 Fuse 6.0A 125V (220V ~ 240V)
to be continued >
