16
OUT
IN
OUT
IN
OUT
IN
VCR TO TV CONNECTION
After you have connected the antenna to the VCR (see pages 14 & 15), you must connect the VCR to the TV.
Below are 3 common methods of connecting your VCR to a TV. Find the type of TV you are using and follow
the connection diagram.
2
1
3
BASIC CONNECTIONS (CONTINUED)
75 Ohm Coaxial Cable (Supplied)
75 Ohm Coaxial Cable (Supplied)
75 Ohm Coaxial Cable (supplied)
VCR
VCR
VCR
4C83101B(P10-19) 9*9*99, 10:3216
To Next Page
