18
OUT
IN
UHF/VHF
OUT
IN
UHF/VHF
OUT
IN
UHF/VHF
1
3
2
IMPORTANT:
Make sure the TV/CATV menu option is set to the "CATV" mode.
IMPORTANT:
Make sure the TV/CATV menu option is set to the "CATV" mode.
IMPORTANT:
Make sure the TV/CATV menu option is set to the "CATV" mode.
Whenever Converter/Descrambler box is placed before VCR, you must tune the VCR to the out of the
Converter/Descrambler box, usually channel 3 or 4.
NOTE:
CATV (CABLE TV) CONNECTIONS
VCR
VCR
Many cable companies offer services permitting reception of extra channels including pay or subscription channels. This VCR has
an extended tuning range and can be tuned to most cable channels without using a cable company supplied converter box, except
for those channels which are intentionally scrambled. If you subscribe to a special channel which is scrambled, you must have a
descrambler box for proper reception.
Converter/Descrambler
VCR
Converter/Descrambler
Incoming Cable
Incoming Cable
Incoming Cable
4C83101B(P10-19) 9*9*99, 10:3218
To Next Page
