800.533.7533 | Santa-Fe-Products.com Santa Fe Compact70 Installation & Operation Instructions
Service
Replacement Parts
4025560 On/Off Switch
1970010 25A Relay
4027163 15A Relay
4029568 Compressor Overload
4021495 Control Knob
4025577 Clear Hose
4026221 Leveling Foot
4029567 Compressor
4027172 Humidity Control
4033032-03 Run Capacitor
4025569 Hose Adaptor
4035235-03 Fan Capacitor
4033358-08 Coil Set
4034477 Impeller
4036967 Defrost Thermostat
Refrigerant Charging
If the refrigerant charge is lost due to service or a
leak, a new charge must be accurately weighed in. If
any of the old charge is left in the system, it must be
recovered before weighing in the new charge. Refer to
the unit nameplate for the correct charge weight and
refrigerant type.
Compressor/Capacitor Replacement
This compressor is equipped with a two terminal
external overload and a run capacitor, but no start
capacitor or relay.
WARNING!
SERVICING THE SANTA FE COMPACT70, WITH ITS HIGH PRESSURE REFRIGERANT SYSTEM AND HIGH VOLTAGE CIRCUITRY
PRESENTS A HEALTH HAZARD WHICH COULD RESULT IN DEATH, SERIOUS BODILY INJURY, AND/OR PROPERTY DAMAGE.
ONLY QUALIFIED SERVICE PEOPLE SHOULD SERVICE THIS UNIT.
Troubleshooting
CAUTION!
TROUBLESHOOTING SHOULD BE PERFORMED BY A
QUALIFIED HVAC TECHNICIAN.
Symptom Possible Reason
Neither fan nor
compressor
running.
Dehumidication
is being called for.
Compressor is
not running.
Dehumidication
is being called for.
Fan is running.
1. Defective compressor
run capacitor.
2. Loose connection in
compressor circuit.
3. Defective compressor
overload.
4. Defective compressor.
5. Defrost thermostat open.
Compressor
cycles on and off.
Dehumidication
is being called for.
1. Low ambient
temperature and/or
humidity causing unit
to cycle through
defrost mode.
2. Defective compressor
overload.
3. Defective compressor.
4. Defrost thermostat
defective.
5. Dirty air lter(s) or air
flow restricted.
6. Defective fan or relay.
1. Dehumidier unplugged
or no power to outlet.
2. Humidity control set
too high.
3. Loose connection in
internal or control wiring.
4. Defective compressor
relay.
