Santint S5 - Technical Features and Parameters

Santint
Automatic Shaker V1.0 4
3. Technical features and parameters
NO.
Item
Model
□ S5
□ SHH-IV
1
Dimension
（W×D×H）
625×730×1160
775×805×1175
2
Weight（kg）
200±5
215±5
3
Inner Size
Bottom Of Can≤310mm，
Top Of Can≤360mm，
Height≤390mm
Bottom Of Can Without Active
Platform≤360mm
Can Diameter≤360mm，Height≤390mm
4
Travel
Distance Of
Clamping
Plate
50～410 mm
50～410 mm
5
Minimum
Height Of
Can
50 mm
50 mm
6
Weight
Range To
Be Shaken
1～35kg
1～35kg
7
Max Weight
To Be
Shaken
35kg
35kg
8
Power
Supply
AC220V 50Hz
AC220V 50Hz
9
Power Of
Main Motor
750w
750w
10
Motor
Rotation
Speed
1400 RPM
1400 RPM
11
Shaking
Frequency
□680 times/minute
□720 times/minute
Other： times/minute
□680 times/minute
□720 times/minute
Other： times/minute
12
Shaking
Time
Default time 60s/180s/300s
Desired time: T1-__T2__T3__
Units: □s □min
Default time 60s/180s/300s
Desired time: T1-__T2__T3__ Units: □s
□min
