the machine serial number and
the electrical specifications (16)
recorded under the machine.
Replacing the grindstones:
IMPORTANT: always change both 2 grindstones (9) at the same
time. (use SANTOS reference 00001B)
The 2 grindstones are identical and can be fitted equally either on the moving plate (18)
(moving grindstone) or on the adjusting "nut" (5) (fixed grindstone) (fig. P and fig. Q).
1. Close the bean shutter (6) (fig. G).
2. Run the machine until the coffee beans waiting in the grinder body have passed
through.
3. Stop the machine and unplug the mains power lead (10).
4. Take off the bean container (2).
5. With one hand, press the indexing pointer (7) and with the other unscrew the
adjustment nut (5), turning it in an anti-clockwise direction (fig. N).
Care: When fully unscrewed, handle this part with care so as not to damage the brass
thread.
6. Unscrew the 3 screws (32) on each grindstone (fig. O and fig. Q). For the moving
grindstone, place a screwdriver across the grinder body and the coffee outlet tube to
stop the grindstone carrier plate from turning on unscrewing or tightening the
grindstone retaining screws.
7. Carefully clean the whole grinder body, in particular the grindstone facing areas.
8. Place each grindstone on its support making sure that there is no coffee dust
between the grindstone and its support.
CARE: The slightest small coffee particle under the grindstone may prevent the
machine from operating correctly. It is recommended that the grinder body is cleaned
with a compressed air jet or a dry brush.
CARE: Do not unscrew the retaining shaft (17) from the grindstone carrier plate (18)
so as not to upset the geometry of the assembly (fig. P).
9. Once both the grindstones have been replaced, with one hand press the indexing
pointer (7) and with the other place the ground coffee adjustment nut (5) onto the
grinder body taking care not to damage the thread. Without using force, put the nut
(5) on the grinder body, unscrewing it gently to feel for alignment of the two threads
and thus to be able to feed them in without using force. Then tighten until the 2
grindstones come into contact (fig. S).
10. Unscrew the "adjustment nut" (5) to free the grindstones in contact.
11. Plug the machine in and switch it on with no coffee.
