Santos 60 - Machine Technical Specifications

SANTOS : User and maintenance manual
98160 EN 2.2 - 11 2013 16 / 29 www.santos.fr
MACHINE TECHNICAL SPECIFICATIONS
ELECTRICAL SPECIFICATIONS (1)
Model 60
Single phase
Power supply voltage
.(V)
220-240 100-120
Frequency
(Hz)
50/60 50/60
Motor: rating
Input power
(W)
600 800
Speed:
(rpm)
2850 at 50 Hz, 3400 at 60
Hz
Bean container capacity
(kg)
2.2
Grindstone diameter
(mm)
63.5
Average output
(Kg/h)
15
Dose measurement adjustment (approx.)
(g)
From 5.5 to 9.5
Dose measurer capacity
(kg)
0.2
Automatic start and stop
Every 2 to 4 doses
Dimensions: Height
(mm)
580
Width
(mm)
190
Depth
(mm)
390
Weight: Net weight
(kg)
14
Packaged weight
(kg)
16
Noise: (2)
(dBA)
63
(1) These values are given as an indication only. The exact electrical specifications for your
machine are given on the identification plate.
(2) Noise level measured in acoustic pressure with the machine under load at 1 m from its axis in
accordance with standard EN 31201.
