FITTING AND REMOVING THE REMOVABLE DOSE MEASURER:
Note: If the dose measurer (31) is not properly positioned and locked onto the No. 60
coffee grinder, it will not start. If the lid (24) with the detection paddle (14) and its
magnet (19) is not properly positioned and fitted onto the dose measurer, the No. 60
coffee grinder will not start (fig. H).
Removing and refitting the removable dose measurer:
The removable dose measurer can be removed and refitted either to provide for the
dispensing of different ground coffee qualities from a No. 60 coffee grinder or from a
SANTOS No. 56 base-mounted dose measurer or from a SANTOS No. 57 wall-mounted
dose measurer, or to remedy an after-sales service problem quickly:
• Removal of a dose measurer placed on the No. 60 coffee grinder to put it on a
SANTOS No. 56 base-mounted dose measurer or a SANTOS No. 57 wall-mounted
dose measurer. To facilitate changing and fitting the dose measurer in this case, it
is recommended that the dose measurer lid is taken off with the detection paddle
and its magnet and the coffee outlet area cleared to avoid losing ground coffee on
removal (brush supplied).
• Removal of the dose measurer to replace it quickly by another (for adjustment,
cleaning, repair, etc.).
Fitting the removable dose measurer:
1. Take off the dose measurer lid (24).
2. Press the lever (30) to retract the dose measurer locking pin (29).
3. Remove the removable dose measurer (31) holding it by the tamper (20).
Release the bottom of the dose measurer first (rotation), then downwards to
unhook it.
4. Release the lever (30) to allow the dose measurer locking pin (29) to move back
to the ready position.
Fitting the removable dose measurer:
5. Fit the removable dose measurer (31) by positioning the dose measurer slot in
the dose measurer support plate hook (26), then give a turning movement to
engage it on the locking pin (29). Push the dose measurer fully in to the support
plate (26) to lock the removable dose measurer (31) in position.
6. Check the dose measurer (31) is properly locked on by pulling on the tamper
nose (20)
7. Refit the dose measurer lid (24) by positioning correctly and inserting fully onto
the dose measurer (31) transparent cylinder.
