Sanus BLL2 - Step 2 B: Concrete Installation - Drilling; Drill Pilot Holes in Concrete

14
Never drill into the mortar between blocks.
CAUTION:
Never drill into the mortar between blocks.
2
DRILL
4X
CAUTION:
3
REMOVE TEMPLATE
Remove the wall plate template
14
and discard.
14
14
3/8 in.
(10 mm)
3 in. (7.6 cm)
Drill four pilot holes using a 3/8 in. (10 mm) diameter drill bit.
IMPORTANT: Pilot holes must be drilled to a depth of 3 in. (7.6 cm).
STEP 2B (continued)
