Sanus BLL2 - Step 2 B: Concrete Installation - Finalizing; Insert Anchors and Secure Wall Plate

15
15
4X
14
3
17
4X
CAUTION:
Be sure the anchors
17
are seated fl ush
with the concrete surface.
CAUTION:
5
SECURELY TIGHTEN
Insert four anchors
17
.
34
INSERT ANCHORS
16
18
Install the four screws
16
and tighten only until they are pulled
firmly against the wall plate
15
.
Improper use could reduce the holding power of the screws
16
.
DO NOT over-tighten the screws
16
.
CAUTION:
Avoid potential personal injury or property damage!
Go to STEP 3 on PAGE 19
