NOTE: Not all hardware included will be used.
WARNING: This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to
your dealer; contact Customer Service. Never use damaged parts!
Supplied Parts and Hardware
STEP 1 Parts and Hardware
TV Bracket
TV Bracket Extenders*
†Nylon locking bracket nuts
are poly-locks and will need to
be forcibly tightened.
03
x4
04
x4
05
x4
07
x4
09
x4
06
x4
08
x4
10
x4
11
x4
12
x4
13
x4
02
x2
01
x1
TV Screws, Washers, and Spacers
M6 Extension
Bracket Screws* M6 Nuts*†
*Only needed for TVs
with 20.0 x 20.0 cm
(7 7⁄8 x 7 7⁄8 in.) hole
patterns
