Sanus F215 - Page 7

7
03
D E
03
200
[7 ⅞ in.]
200
[7 ⅞ in.]
01
Assemble TV brackets
02
onto Faceplate
01
and secure using eight screws
03
in
the corner holes indicated.
Assemble TV brackets
02
onto Faceplate
01
and secure using eight screws
03
in
the corner holes indicated.
01
02
02
02
02
C
03
Assemble TV brackets
02
onto Faceplate
01
and secure using eight screws
03
in
the corner holes indicated.
02
02
01
400
[15¾ in.]
400
[15 ¾ in.]
400
[15¾ in.]
300
[11 ¾ in.]
300
[11 ¾ in.]
300
[11 ¾ in.]
400 x 300
For TV Hole Pattern
Measurements
(Dimensions in mm)
300 x 200
400 x 200
For TV Hole Pattern
Measurements
(Dimensions in mm)
200 x 300
200 x 400
For TV Hole Pattern
Measurements
(Dimensions in mm)
