Sanus FSF207 - Step 3: Hang TV onto Wall Plate; Hang TV onto Wall Plate Arm; Lock TV to Wall Plate Assembly

20
HEAVY! You may need assistance with this step.
STEP 3 Hang TV onto Wall Plate
1. Hang the TV onto the arm of wall plate assembly
15
by first hooking the top support, then resting the TV into place.
2. Lock the TV to the wall plate assembly
15
with locking screw
18
and washer
19
.
CAUTION! This locking screw
18
must be installed to secure the TV onto the wall plate assembly
15
.
15
15
55
1 2
18
19
