STEP 1 Attach TV Bracket to TV
These smaller hole patterns only use TV bracket
01
.
Do not use the four TV bracket extenders
02
and eight screws
03
.
7.5 x 7.5
10.0 x 10.0
01
10.0
10.0
7.5
1-1 Measure Your TV Hole Pattern 1-2 Assemble Your TV Bracket
Determine which TV bracket configuration to use, A, B, or C
based on your TV hole pattern measurements.
cm
inches
02
03
inch dimensions are approximate
75 mm = 7.5 cm ≈ 3 in.
100 mm = 10 cm ≈ 4 in.
200 mm = 20 cm ≈ 7⅞ in.
Measure the width and height of your TV hole
pattern in cm.
Record your measurements:
Width __________ cm x Height ________ cm
A
7.5
