Assemble TV bracket extenders
02
onto TV bracket
01
as
illustrated.
Secure using eight screws
03
in the corner holes shown.
B C
20.0 x 20.0
01
20.0
20.0
02
02
02
02
03
Assemble TV bracket extenders
02
onto TV bracket
01
as
illustrated.
Secure using eight screws
03
in the corner holes shown.
20.0 x 10.0
20.0
10.0
01
02
02
02
02
03
