Solid Concrete or Concrete Block Installation
3 4
09
10
UP ARROW
Install the wall plate
08
using six lag bolts
09
and washers
10
into
the anchors
11
. Tighten all lag bolts
09
only until the washers
10
are
pulled firmly against the wall plate.
CAUTION: Avoid potential personal injury or property damage!
All six lag bolts
09
MUST BE firmly tightened to prevent unwanted
movement of the wall plate
08
.
Ensure the wall plate is securely
fastened to the wall before continuing on to the next step.
11
4X
4X
4X
2X
2X
2X
08
